SkyScan 1173 Micro-CT

Micro CT Scanner with 2D/3D Image Analysis and Realistic Visualization

The SkyScan 1173 is a high energy microtomography (micro-CT) scanner for large and dense objects and also has the flexibility to image low dense materials. The SkyScan 1173 Micro CT system includes a newly developed 130kV microfocus X-ray source with improved stability of focal spot position, a large format (>5Mp) flat panel sensor with special protection by lead-glass fiber-optic window for long lifetime under high-energy X-ray, a precision object manipulator for large (up to 140mm) and heavy (several kg) objects with embedded micropositioning stage.

Introduction to X-ray Microtomography (Micro-CT)

Microtomography uses a similar technique as X-ray tomography systems used in medicine (CT Scans) but with much finer resolution. Multiple 2D X-ray images are stored while either the sample or the source / detector pair is rotated. Internal structures are reconstructed as a series of 2D cross sections (up to 2240 in a single scan) which are then used to analyze the two and three dimensional morphological parameters of the object. The process is nondestructive and requires no special preparation of the specimen. For comparison, medical CT systems have pixel sizes in the range of 1mm, the Skyscan 1173 Microtomograph can acquire images with 4 micron pixel size.

The powerful imaging capabilities of X-ray tomography are now available in a range of desktop instruments suitable for microscopic imaging of small objects with a wide range of applications: 3D bone analysis, food studies, soft tissue research, insects, microelectronics, materials, geological studies and more. Specialized software (CTAn) has been developed for the analysis of Micro-CT images including bone morphometry, porosity, fractal analysis and more (see related pages).

Call Ben at (610) 366-7103 or email: ben@microphotonics.com

  • New 16Mp or 11Mp cooled 14bit X-ray detector in one, two or three offset positions
  • Up to 14450×3240 pixels in every image, 209Mp in each of 2600 slices reconstructed after one scan
  • Down to 0.35µm isotropic detail detectability with phase contrast enhancement for submicron details
  • Automatically variable acquisition geometry for shortest scan at any magnification
  • Integrated micro-positioning stage allows easy finding most optimal sample placement,
  • Scanning sample during compression, tension, heating, cooling (optional stages
  • Standard automatic filter changer with 6 positions and wide range of source energy selection
  • 2D/3D image analysis and realistic visualization
  • Optional 16-position automatic sample changer
  • X-ray source
    20-100kV, 10W, <5µm spot size
  • X-ray detector
    16 mega-pixel (4904 x 3280 pixels) or 11 mega-pixel (4032 x 2688 pixels), 14-bit cooled CCD fiber-optically coupled scintillator
  • Maximum object size
    75mm in diameter, 70mm in height
  • Spatial resolution
    0.35um (16 mega-pixel camera) and 0.45um (11 mega-pixel) detail detectability
  • Reconstruction
    Single PC or cluster volumetric reconstruction (Feldkamp algorithm)
  • Optional stages
    Cooling, heating, compression / tension
  • Radiation safety
    <1µSv / h at any point on the instrument surface
  • Dimensions
    1160W x 520D x 330H mm (440H with sample changer)
  • Weight
    150kg uncrated

For the latest releases of the SkyScan software please visit SkyScan’s website.

If you need any assistance please contact us at 1-866-334-4674 or info@microphotonics.com.
